Category:

Specifications

  • Based on TRRW-9010, TRRW-9018 is added with low-pressure suction S-1, breath resuscitation bag HF-I, oxygen cylinders and infant head fixing unit TJ-I;
  • Pre-warm mode, manual mode and baby mode controlled by micro-computer;
  • Set temperature and baby temperature can be displayed separately;
  • Horizontal angle of warmer module can be adjusted;
  • Inclination of the bassinet can be adjusted, and the organic glass panels can be turned outward or disassembled;
  • X-ray cassette is under the bassinet;
  • APGAR timer;
  • Power supply: AC220V-230V/60Hz
  • Maximum Power Output: 600W
  • Mode of control: Pre-warm mode control, manual mode control and baby mode control by micro-computer
  • Baby mode temperature control range: 34.5-37.5°C
  • Temperature sensor display range: 5°C-65°C
  • Accuracy of skin temperature sensor: 50.3°C
  • Temperature uniformity of mattress: 52°C
  • Angle of heater head: 0°,30°,60° for two ways;
  • Inclination of the bassinet: the three tile position;
  • APGAR timer: it will give sound when the unit is tones at 1′,5′, 10′;
  • Failure alarm: over temperature alarm, deviation alarm, sensor failure alarm, power failure alarm, setting alarm, checking alarm and so on.
    Environmental temperature Operating range: 18°C–30°C
  • Ambient air movement rate: 50.3m/s
